Product Highlight:
This near-new (99% condition) Stainless Steel Slitting Machine delivers precision slitting of 0.3-3.0mm stainless at 180 m/min, featuring a hardened Ø200mm shaft with 60 tungsten blades, 260KW synchronized drive system, and AI tension control – offering industrial-grade performance at 40% of new-equipment cost for food, architecture, and electronics applications.
This Industrial Stainless Steel Cutter represents the optimal solution for high-precision metal processing, offering exceptional value as a lightly used Stainless Steel Slitting Machine with only 800 operational hours (equivalent to 99% new condition). Designed specifically for challenging stainless steel applications, this 1650mm-wide Stainless Steel Slitting Machine processes materials from ultra-thin 0.3mm foils to heavy 3.0mm 304 steel with mirror-finish quality (Ra ≤ 0.8 μm). The integrated vector control system and hardened Ø200mm slitting shaft deliver performance metrics rivaling new installations, making it ideal for cost-conscious manufacturers requiring uncompromised precision.
Drive System Configuration
Precision Subsystems
Hardened Slitting Shaft: Chromium-plated Ø200mm shaft (HRC 60) maintains ≤0.003mm runout at 180 m/min
Blade Configuration: 60 Tungsten Carbide Blades (0.5-3.0mm thickness) included
Cross-Cut System: Front/Rear Hydraulic Guillotine Shears (±0.2mm cut accuracy)
AI Tension Optimization: Real-time compensation for thickness variations
200mm Slitting Shaft: Unmatched Rigidity
As the core of this Industrial Stainless Steel Cutter, the Ø200mm shaft delivers critical advantages:
Vibration Control: Anti-resonance design eliminates harmonic distortion during high-speed processing
Thermal Stability: ≤5μm thermal deflection at continuous 180 m/min operation
Blade Alignment: Precision ground spacers maintain ±0.15mm width tolerance across full 1650mm width
60-Blade Cutting System
Material Versatility: Configured for stainless grades 304, 316L, 430, and duplex steels
Edge Quality: Burr-free slitting (Ra ≤ 0.8μm) meets food-grade (316L) and medical standards
Quick-Change Design: Blade replacement within 15 minutes using patented alignment tools
Vector Inverter Control System
Motor Synchronization: Coordinates 4 independent drives with ±0.1% speed matching
Dynamic Response: 0→180 m/min acceleration in 25 seconds with zero material stretch
Tension Management: Auto-taper control maintains ±1.5% tension from full coil to core
Energy Recovery Technology
◉ Regenerative braking converts deceleration energy into reusable power
◉ 22% average energy reduction versus conventional drives
◉ Power factor correction maintains >0.95 efficiency at all speeds
Operational Economics
Throughput: 12 tons/hour at 180 m/min with 0.5mm material
Changeover: Full blade configuration swap ≤30 minutes
Uptime: 98.7% documented in food-grade production
Maintenance Cost: 60% lower than comparable new systems
Intelligent Control Features
Auto Diameter Calculation: PLC-based tension taper profiling
Thickness Compensation: Laser sensors adjust blade gap in real-time
Production Logging: OEE tracking with defect mapping
Safety System Certification
Category 4 PLd Safety (ISO 13849-1)
Dual-channel light curtain protection (14mm resolution)
Emergency stop reaction <0.3 seconds
Energy-isolating blade guards with safety interlocks
